- Size: 0.001
- Place of Origin: CHINA
- Brand Name: anfang
- Model Number: 2030
- Weight: 0.004 kg
NON SPAEKING ALLEN WRENCH , HEX KEY SPANNER , ALUMINUM BRONZE OR BERYLLIUM COPPER EXPLOSION PROOF , FOR NUTS
Features Of Hex Key Wrench
1. The Hand Tool Is Simple And Lightweight.
2. It Can Be Used To Tighten The Screw In The Hole.
3. The Wrench Diameter And Length Determines Its Torsional Forces.
4. It Can Be Easily Manufactured, Ensuring Low Cost.
5. Both Ends Of The Hex Key Wrench Can Be Used.
3mm 4mm 5mm 6mm 8mm 10mm 12mm 14mm 17mm 19mm 22mm 24mm 27mm 30mm 32mm 36mm
No. | Φmm | Φ’’ | No. | Φmm | Φ’’ |
101 | 3 | 1/8’’ | 109 | 17 | 3/8’’ |
102 | 4 | 5/32’’ | 110 | 19 | 7/16’’ |
103 | 5 | 3/16’’ | 111 | 22 | 1/2’’ |
104 | 6 | 7/32’’ | 112 | 24 | 9/16’’ |
105 | 8 | 1/4’’ | 113 | 27 | 5/8’’ |
106 | 10 | 9/32’’ | 114 | 30 | 11/16’’ |
107 | 12 | 5/16’’ | 115 | 32 | 3/4’’ |
108 | 14 | 11/32’’ | 116 | 36 | 13/16’’ |
- Size: 0.001
- Place of Origin: CHINA
- Brand Name: anfang
- Model Number: 2030
- Weight: 0.004 kg
Beryllium bronze | Al:0.15%, Fe:0.15%, Si:0.15% , Ni: 0.2-0.4% Ti: 0.1-0.25% Be: 1.8-2.0% Cu , others 0.6%
|
aluminum bronze | Al:9-10% Mn:3-5% Fe:3-4% Ni: 5% Cu
|
Copper alloy | Al:9% Co:8% Ni: 2-3% Cu |
