- Size: 0.03
- Place of Origin: hebei
- Brand Name: anfang
- Model Number: 2004
- Weight: 0.020 kg
.The processing procedure
Step1) To prepare the raw material, blanking
Step2) Smelting
Step3) Pouring
Step4) Cut the water gap
Step5) Stored in the semi finished products warehouse
Step6) Punching
Step7) Through the drawbench or slotting machine
Step8) PE plain end and chamfering
Step9) Drill hole
Step10) Perfect the product and marking
Step11) If Be-bronze,need heat treatment
Step12) Polishing
Step13) Surface treatment
3.Surface treatment
1) Electrostatic spraying
2) Natural color
3) Passivation
4. Specs
Terrace Measuring Tools.
1. Machinery production
2. Installation of the machine
3. Lineation , marking out and measuring
- Size: 0.03
- Place of Origin: hebei
- Brand Name: anfang
- Model Number: 2004
- Weight: 0.020 kg
Φmm | ♦''AF | No. | Φmm | ♦''AF | |
101 | 5.5*7 | 1/4*5/16 | 115 | 32*34 | 1-1/8*1-3/16 |
102 | 6*7 | 5/16*3/8 | 116 | 32*36 | 1-3/16*1-1/4 |
103 | 8*10 | 3/8*7/16 | 117 | 34*36 | 1-1/4*1-5/16 |
104 | 9*11 | 7/16*1/2 | 118 | 36*38 | 1-5/16*1-3/8 |
105 | 10*12 | 1/2*9/16 | 119 | 36*41 | 1-3/8*1-7/16 |
106 | 12*14 | 9/16*5/8 | 120 | 38*41 | 1-7/16*1-5/8 |
107 | 14*17 | 5/8*11/16 | 121 | 41*46 | 1-5/8*1-13/16 |
108 | 16*18 | 11/16*3/4 | 122 | 46*50 | 1-13/16*2 |
109 | 17*19 | 3/4*13/16 | 123 | 50*55 | 1-11/16*1-7/8 |
110 | 19*22 | 13/16*7/8 | 124 | 55*60 | 2-3/16*2-3/8 |
111 | 22*24 | 7/8*15/16 | 125 | 60*65 | 2-9/16*2-31/32 |
112 | 24*27 | 15/16*1 | 126 | 65*70 | 2-7/8*2-3/4 |
113 | 27*30 | 1*1-1/16 | 127 | 70*75 | 2-5/8*2-7/16 |
114 | 30*32 | 1-1/16*1-1/8 | 128 | 65*75 | 2-1/4*2-1/8 |
